Eco - Friendly And Rechargeable White Color 1500W 24V Wind And Solar Hybrid Controller For Home

Brand Name : HYE

Model Number : HY-C15-24BSLS

Certification : CE, ISO9001,RoHS

Place of Origin : Guangzhou,China

MOQ : 1 PCS

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000sets/month

Delivery Time : 3-5days

Packaging Details : standard export packing

Rated Wind Power : 1500W

Max. Wind Input Power : 3KW

Rated Solar Power : 300W

Max. Solar Input Power : 600W

Contact Now

  • Eco - friendly and Rechargeable 1500W 24V Wind Solar Hybrid Controller For Home
  • Installation and Electrical Connection
  • Installation
  • Warning
  • Please read this chapter carefully before installation to make sure the whole process is safe.
  • It is important to choose where to install the controller. Keep the controller away from rain, insolation. Put the controller in a dry, ventilated place.
  • Metal materials placed around the controller are prohibited. If not may cause battery short circuit.
  • There should be enough space around the controller for cooling.
  • This controller could only charge to the lead-acid batteries which are in the control range of this controller.
  • Not fully connection and corrosive wire will produce lot of heat. Then wire insulation layer may be melted, lead surrounding material combustion, even fire. So please ensure every connection is secure, to avoid connector loose when moving.

  • Installation Steps
  • Step 1: Select location Do not install the controller in a place where insolate, high temperatureand rainy. Please keep enough free air around the controller.
  • Step 2: Inspect Put the controller on the place where it will be installed. Inspect if thereis enough space for connections.
  • Step 3: Mark Mark with 4 dots on install surface through controller’s 4 open holes.
  • Step 4: Drill holes Drill 4 holes in the 4 dots which were marked in step 3.
  • Step 5: Fix controller Aim controller’s 4 open holes toward the 4 holes which were drilled in step 4. Then fix controller with screw nails.
  • Step 6: Check Make sure the controller is firmly installed.

Technical Data

Product Model

HY-C15-24BSLS

Rated Wind Turbine Power

1.5KW

Max. Wind Input Power

3KW

Rated Solar Power

300W

Max. Solar Input Power

600W

Rated Battery Voltage

24V

Over-discharge Voltage

20.4V(adjustable)

Over-discharge Recovery Voltage

23.0V(adjustable)

Over-charge Voltage

28.8V(adjustable)

Over-charge Recovery Voltage

26.0V(adjustable)

Floating Voltage

27.0V(adjustable)

Dump-load start Voltage

100V(adjustable)

Dump-load start Rotate Speed

500RPM(adjustable)

Wind start Charging Voltage

10V

Wind Turbine Charging Mode

MPPT and PWM

Solar Charging Mode

PWM

Controlling Dump-load Mode

Over rotate speed limiting, Over voltage limiting, Over Current limiting, PWM

Display Mode

LCD

Display content

Voltage of battery, solar and wind. Current of battery, solar and wind; Power of wind, solar and battery; System state, and so on.

Operating Temperature & Relative Humidity

﹣20~﹢55℃/35~85%RH(Non-condensing)

Quiescent Power Drain

≤3W

Protection Type

Solar cells and battery anti-reverse connection; Battery over-charge, over-discharge, over-charge recovery, over-discharge recovery, etc.; Load over-charge and over-discharge; Wind turbine brake automatically and manually

Package Size(L*W*H)

510mm*250mm*545mm

Gross Weight

16.0Kg

Communication Mode (optional)

RS232,RS485

Storage (optional)

USB


Company Picture:

Eco - Friendly And Rechargeable White Color 1500W 24V Wind And Solar Hybrid Controller For Home



FAQ

1. Which payment terms are available?
A: Our company accept Telegraphic Transfer (T/T) payment for sample and bulk order.

2. How long will my order ready?
A: The delivery time is within 5 working days upon the payment receipt for the sample order.

3. I need the other accessories besides the wind turbine, do you also provide them?
A: Yes, we can supply not only the wind turbine but also the other parts of the system. E.g: controller, inverter.

Can you help me to design the system for my home and provide all accessories?
A: No problem. We can give you professorial technical advice and design the power system according to your request.
